MS 116GS

Description

The MERCUSYS MS116GS is a high-performance 16-Port Gigabit Desktop/Rackmount Switch designed to expand wired network connectivity for homes, offices, surveillance systems, gaming setups, schools, shops, and small business environments. Equipped with sixteen 10/100/1000 Mbps Gigabit Ethernet ports, the switch provides stable, high-speed data transmission for multiple devices such as computers, laptops, printers, IP cameras, smart TVs, gaming consoles, NAS storage systems, wireless access points, and routers. Its full Gigabit architecture delivers transfer speeds up to 10 times faster than traditional Fast Ethernet switches, making it ideal for high-bandwidth networking applications. The MS116GS features a powerful 32 Gbps switching capacity and a non-blocking switching architecture that allows data packets to be forwarded and filtered at full wire speed. This ensures smooth network performance even during heavy traffic conditions such as HD video streaming, online gaming, cloud synchronization, large file transfers, surveillance monitoring, and video conferencing. The switch uses Store-and-Forward forwarding technology to improve transmission reliability and packet accuracy. One of the major highlights of the MS116GS is its Isolation Mode and Loop Prevention functionality. Isolation Mode enables one-click traffic separation between ports to enhance LAN security and reduce broadcast storms, helping prevent unauthorized access and improving overall network performance. The Loop Prevention feature automatically detects network loops and blocks problematic ports to prevent network disruptions and instability caused by accidental looping connections. These features make the switch particularly useful for surveillance networks, offices, and shared environments where stable connectivity and traffic control are important. The switch supports IEEE 802.3x Flow Control and 802.1P/DSCP QoS (Quality of Service) technology, helping prioritize important traffic for smoother and more reliable network performance. QoS improves the experience for latency-sensitive applications such as VoIP calls, video meetings, and streaming by optimizing packet handling during congestion. The MS116GS is designed with a durable metal casing that improves heat dissipation, protects internal components, and ensures long-term reliability. Its fanless silent design allows completely quiet operation, making it suitable for offices, meeting rooms, libraries, classrooms, and home environments where low noise is important. The device supports both desktop placement and rackmount installation, providing flexible deployment options depending on the network setup. Installation is extremely simple thanks to plug-and-play functionality. No software installation or complicated configuration is required. Each Ethernet port supports Auto-Negotiation and Auto-MDI/MDIX, automatically detecting the correct connection speed and cable type for hassle-free setup. Users simply connect the switch to their router or network devices using Ethernet cables, and the switch begins operating instantly. The MS116GS also includes energy-efficient Ethernet technology that automatically adjusts power consumption based on cable length and connection status to reduce electricity usage and improve energy efficiency. The switch supports IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, and IEEE 802.1p networking standards, ensuring broad compatibility with modern networking devices and infrastructure. Hardware specifications include sixteen Gigabit RJ45 ports, an 8K MAC address table, Power/Link/Act LED indicators, and support for Cat5e/Cat6 Ethernet cables up to 100 meters in length. The switch operates using a 100-240V AC power supply and functions within operating temperatures of 0°C to 40°C. Package contents include the MS116GS switch, power cord, rackmount kit, rubber feet, and installation guide. Community discussions on Reddit frequently describe MERCUSYS switches as affordable and practical networking solutions for users needing reliable Gigabit Ethernet expansion. Some users also mention that MERCUSYS products share similarities with TP-Link hardware because both brands belong to the same parent company, making them attractive budget-friendly alternatives for home and office networking.

Specifications

Product Model

MS116GS

Product Type

16-Port Gigabit Desktop/Rackmount Switch

Ports

16× 10/100/1000 Mbps RJ45 Ports

Port Features

Auto-Negotiation, Auto-MDI/MDIX

Switching Capacity

32 Gbps

MAC Address Table

8K

Forwarding Method

Store and Forward

Network Standards

IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1p

QoS Support

QoS Support

Flow Control

IEEE 802.3X Flow Control

Advanced Features

Isolation Mode, Loop Prevention

LED Indicators

Power, Link/Act, 1000Mbps

Casing

Durable Metal Casing

Cooling Design

Fanless Silent Operation

Installation Type

Desktop & Rackmount

Power Supply

100-240VAC, 50/60Hz

Cable Support

Cat5/Cat5e/Cat6 Ethernet Cable

Maximum Cable Length

100 meters

Operating Temperature

0°C to 40°C

Storage Temperature

-40°C to 70°C

Operating Humidity

10% to 90% Non-Condensing

Storage Humidity

5% to 90% Non-Condensing

Dimensions

294 × 140 × 44 mm

Certifications

CE, RoHS

Package Contents

MS116GS Switch, Power Cord, Rackmount Kit, Rubber Feet, Installation Guide
